| 1 |
17521-NC2-000 |
HOOK, FUEL CAP BREATHER (se) |
1 |
0.00 |
|
| 2 |
30400-ND4-010 |
UNIT ASSY, CDI (se) |
1 |
0.00 |
|
| 3 |
37250-NC8-010 |
TACHOMETER ASSY (se) |
1 |
0.00 |
|
| 4 |
37460-NC8-003 |
METER, WATER TEMPERATURE (se) |
1 |
0.00 |
|
| 5 |
50801-ND4-750 |
SCREW, COWL (6x13) (se) |
5 |
0.00 |
|
| 6 |
50803-ND4-750 |
NUT, COWL STAY (se) |
1 |
0.00 |
|
| 7 |
50810-ND4-750 |
STAY COMP, CENTER COWL (se) |
1 |
0.00 |
|
| 8 |
50811-ND4-750 |
BAND (D=25.4mm) (se) |
1 |
0.00 |
|
| 9 |
50815-NC8-000 |
PANEL, METER (se) |
1 |
0.00 |
|
| 10 |
64100-ND4-750 |
FRONT COWL SET (se) |
1 |
0.00 |
|
| 11 |
64101-ND4-750 |
SCREEN, FRONT COWL (se) |
1 |
0.00 |
|
| 12 |
64210-ND4-760 |
STAY, REAR COWL (se) |
2 |
0.00 |
|
| 13 |
64211-NC2-000 |
RUBBER, COWLING SET (se) |
4 |
0.00 |
|
| 14 |
64240-ND4-760 |
STAY, CENTER COWL (se) |
2 |
0.00 |
|
| 15 |
64255-NC2-000 |
FASTENER,COWLING (se) |
5 |
0.00 |
|
| 16 |
90301-473-003 |
U-NUT (6mm) |
3 |
4.15 |
|
| 17 |
90351-NC2-000 |
NUT, SELF LOCK (3mm) (se) |
7 |
0.00 |
|
| 18 |
93494-06025-00 |
BOLT-WASHER (6x25) |
2 |
0.65 |
|
| 19 |
93500-03010-0A |
SCREW, PAN HEAD (3x10) |
7 |
0.40 |
|
| 20 |
94101-03000 |
WASHER, PLAIN (3mm) |
14 |
0.35 |
|
| 21 |
95700-08016-00 |
BOLT, FLANGE (8x16) [USE 95701-08016-00] |
2 |
0.60 |
|
| 22 |
96000-06012-00 |
BOLT, FLANGE (6x12) [USE 96001-06012-00] |
2 |
0.60 |
|
| 23 |
96000-06020-00 |
BOLT, FLANGE (6x20) [USE 96001-06020-00] |
1 |
0.60 |
|
