| 1 |
13615-KS6-700 |
GEAR, PRIMARY DRIVE (20T) |
1 |
44.70 |
|
| 2 |
13617-KS6-700 |
COLLAR, PRIMARY DRIVE GEAR |
1 |
23.20 |
|
| 3 |
22100-KS6-700 |
CLUTCH, OUTER (63T) [USE 22100-KZ4-700] |
1 |
300.35 |
|
| 4 |
22120-NF4-000 |
CENTER, CLUTCH (se) |
1 |
0.00 |
|
| 5 |
22125-435-000 |
SEAT, SHUDDER SPRING |
1 |
4.65 |
|
| 6 |
22201-NF4-000 |
DISK, CLUTCH FRICTION [USE 22201-KRN-670] |
6 |
13.10 |
|
| 7 |
22202-NF4-000 |
DISK A, CLUTCH FRICTION (se) |
1 |
0.00 |
|
| 8 |
22321-NF4-000 |
PLATE, CLUTCH (se) |
6 |
0.00 |
|
| 9 |
22351-NF4-000 |
PLATE, CLUTCH PRESSURE (se) |
1 |
0.00 |
|
| 10 |
22352-KA4-000 |
PIECE, CLUTCH LIFTER |
1 |
24.40 |
|
| 11 |
22401-KA3-710 |
SPRING, CLUTCH |
5 |
6.15 |
|
| 12 |
22402-435-000 |
SPRING, SHUDDER |
1 |
41.65 |
|
| 13 |
22850-KS6-700 |
ROD, CLUTCH LIFTER (se) |
1 |
0.00 |
|
| 14 |
28237-KS6-000 |
COLLAR, CLUTCH DISTANCE (20x25x25.5) (se) |
1 |
0.00 |
|
| 15 |
90013-430-000 |
BOLT, SPECIAL (10x25) |
1 |
6.15 |
|
| 16 |
90235-KA4-000 |
NUT (18mm) |
1 |
6.30 |
|
| 17 |
90441-HA2-670 |
WASHER,LOCK 18MM [USE 90445-KAE-000] |
1 |
3.25 |
|
| 18 |
90456-KA4-000 |
WASHER, THRUST (18x32) |
1 |
3.30 |
|
| 19 |
90456-KS6-000 |
WASHER (20MM) |
1 |
6.35 |
|
| 20 |
90481-430-000 |
WASHER (10mm) |
1 |
4.95 |
|
| 21 |
91011-KS6-003 |
BEARING (25x29x22) |
1 |
11.15 |
|
| 22 |
93404-06020-08 |
BOLT-WASHER (6x20) |
5 |
0.55 |
|
| 23 |
96211-09000 |
BALL, STEEL (#9) |
1 |
0.25 |
|
