| 1 |
12100-NF4-780 |
CYLINDER COMP (se) |
1 |
1,045.00 |
|
| 2 |
12191-KS6-880 |
GASKET, CYLINDER (se) [USE 12191-NF4-610R] |
1 |
15.25 |
|
| 3 |
12200-NF4-780 |
HEAD COMP, CYLINDER (se) |
1 |
0.00 |
|
| 4 |
12212-ND5-003 |
O-RING, CYLINDER HEAD (96x2.4) (se) |
1 |
4.35 |
|
| 5 |
12213-ND5-000 |
O-RING, CYLINDER HEAD (61x1.9) (se) |
1 |
9.95 |
|
| 7 |
18331-NF4-780 |
GASKET, EXHAUST JOINT (se) |
1 |
10.40 |
|
| 8 |
31903-NF4-871 |
SPARK PLUG 10 [USE R7376-10] |
(1) |
0.00 |
|
|
31901-NF4-771 |
SPARK PLUG 10.5 [USE R6179A-105P] |
1 |
0.00 |
|
|
31902-NF4-871 |
SPARK PLUG 11 [USE R6179A-11P] |
(1) |
0.00 |
|
| 9 |
31910-NF4-000 |
NUT SPARK PLUG (se) |
(1) |
3.00 |
|
| 10 |
90441-422-000 |
WASHER, SEALING (8mm) |
5 |
7.05 |
|
| 11 |
90443-107-000 |
NUT, CAP (8mm) |
5 |
3.50 |
|
| 12 |
90543-273-000 |
PACKING, FRONT FORK DRAIN |
1 |
2.20 |
|
| 13 |
92900-08032-0E |
BOLT, STUD (8x32) |
5 |
0.75 |
|
| 14 |
94050-08000 |
NUT, FLANGE (8mm) |
4 |
0.55 |
|
| 15 |
94301-06100 |
PIN, DOWEL (6x10) |
2 |
0.85 |
|
| 17 |
96001-06010-07 |
BOLT, FLANGE SH (6x10) BLACK |
1 |
0.55 |
|
|
90134-ND5-000 |
BOLT, FLUID CHECK (6x10 SAFETY WIRE HOLES) [USE 90037-NX5-053] |
(1) |
5.85 |
|
