| 1 |
12100-NX4-710 |
CYLINDER COMP [USE 12100-NX4-810] |
1 |
1,524.65 |
|
| 2 |
12194-NX4-781 |
GASKET, CYLINDER (0.4T) (se) |
(1) |
14.75 |
|
|
12195-NX4-781 |
GASKET, CYLINDER (0.5T) (se) |
1 |
14.75 |
|
|
12196-NX4-781 |
GASKET, CYLINDER (0.6T) (se) |
(1) |
14.75 |
|
| 3 |
12200-NX4-710 |
HEAD COMP, CYLINDER (se) |
1 |
276.05 |
|
| 4 |
12212-ND5-003 |
O-RING, CYLINDER HEAD (96x2.4) (se) |
1 |
4.35 |
|
| 5 |
12213-ND5-000 |
O-RING, CYLINDER HEAD (61x1.9) (se) |
1 |
9.95 |
|
| 6 |
13100-NX4-781 |
PISTON COMP, RS125 (1995+) (se) |
1 |
246.55 |
|
| 7 |
13111-KV3-000 |
PIN, PISTON (15mm) |
1 |
14.25 |
|
| 8 |
13112-NX5-700 |
CLIP, PISTON PIN (15mm) (se) |
2 |
3.40 |
|
| 9 |
13121-NX4-811 |
RING, PISTON (se) |
1 |
54.90 |
|
| 10 |
18220-NX4-000 |
JOINT COMP, EXHAUST PIPE (se) [USE 18220-NX4-00S] |
1 |
98.50 |
|
| 11 |
18331-NF4-780 |
GASKET, EXHAUST JOINT (se) |
1 |
10.40 |
|
| 12 |
18359-KS7-000 |
SEAL, EXHAUST PIPE |
1 |
13.10 |
|
| 13 |
90037-NX5-000 |
BOLT, FLUID CHECK (6x10 SAFETY WIRE HOLES) [USE 90037-NX5-053] |
1 |
5.85 |
|
| 14 |
90441-422-000 |
WASHER, SEALING (8mm) |
5 |
7.05 |
|
| 15 |
90443-107-000 |
NUT, CAP (8mm) |
5 |
3.50 |
|
| 16 |
90543-273-000 |
PACKING, FRONT FORK DRAIN |
1 |
2.20 |
|
| 17 |
91101-NX5-023 |
BEARING, PISTON PIN (se) |
1 |
41.20 |
|
| 18 |
92900-08028-0E |
BOLT, STUD 11 (8x28) |
5 |
1.05 |
|
| 19 |
92900-08040-3E |
BOLT, STUD (8x40) |
4 |
0.95 |
|
| 20 |
94050-08000 |
NUT, FLANGE (8mm) |
4 |
0.55 |
|
| 21 |
94301-06100 |
PIN, DOWEL (6x10) |
2 |
0.85 |
|
| 22 |
94301-10160 |
PIN, DOWEL (10x16) |
2 |
0.85 |
|
| 23 |
96001-06014-07 |
BOLT, FLANGE SH (6x14) BK |
3 |
0.55 |
|
